| WEH/WH type electro-hydraulic directional control valve | |||
| WEH/WH type electro-hydraulic directional control valve WH10...4XJ |
specification | 10 | |
| Max woeking pressure(Mpa) | A/B/POil port35|TOil port28 | ||
| Max working Flow(L/min) | 120 | ||
| WEH/WH type electro-hydraulic directional control valve WH16...5XJ、7XJ |
specification | 16 | |
| Max woeking pressure(Mpa) | A/B/POil port35|TOil port25 | ||
| Max working Flow(L/min) | 300 | ||
| WEH/WH type electro-hydraulic directional control valve WH25...5XJ、7XJ |
specification | 25 | |
| Max woeking pressure(Mpa) | A/B/POil port35|TOil port25 | ||
| Max working Flow(L/min) | 650 | ||
| WEH/WH type electro-hydraulic directional control valve WEH10...4XJ |
specification | 10 | |
| Max woeking pressure(Mpa) | A/B/POil port35|TOil port21（DC）/16（AC）|YOil port21（DC）/16（AC） | ||
| Max working Flow(L/min) | 1100 | ||
| Working voltage | Direct Current（DC）24|Communication（AC）220|Self-regulation（SR）220 | ||
| WEH/WH type electro-hydraulic directional control valve WEH16...5XJ、7XJ |
specification | 16 | |
| Max woeking pressure(Mpa) | A/B/POil port35|TOil port21（DC）/16（AC）|YOil port21（DC）/16（AC） | ||
| Max working Flow(L/min) | 1100 | ||
| Working voltage | Direct Current（DC）24|Communication（AC）220|Self-regulation（SR）220 | ||
| WEH/WH type electro-hydraulic directional control valve WEH25...5XJ、7XJ |
specification | 25 | |
| Max woeking pressure(Mpa) | A/B/POil port35|TOil port21（DC）/16（AC）|YOil port21（DC）/16（AC） | ||
| Max working Flow(L/min) | 1100 | ||
| Working voltage | Direct Current（DC）24|Communication（AC）220|Self-regulation（SR）220 | ||
| WEH/WH type electro-hydraulic directional control valve WEH25...1XJ |
specification | 25 | |
| Max woeking pressure(Mpa) | 35 | ||
| Max working Flow(L/min) | 650 | ||
| WEH/WH type electro-hydraulic directional control valve 4WEH32...5XJ、6XJ |
specification | 32 | |
| Max woeking pressure(Mpa) | A/B/POil port35|TOil port21（DC）/16（AC）|YOil port21（DC）/16（AC） | ||
| Max working Flow(L/min) | 1100 | ||
| Working voltage | Direct Current（DC）24/28|Communication（AC）220|Self-regulation（SR）220 | ||
